TF3500 | TwinCAT 3 Analytics Logger

TF3500 | TwinCAT 3 Analytics Logger

TF3500 | TwinCAT 3 Analytics Logger

TF3500 | TwinCAT 3 Analytics Logger

TF3500 | TwinCAT 3 Analytics Logger

Machine commissioning using TwinCAT Analytics

Part 1: TwinCAT Analytics Workflow – Acquiring and communicating data

TwinCAT Analytics One-Klick Dashboard

Machine commissioning using TwinCAT Analytics

Part 1: TwinCAT Analytics Workflow – Acquiring and communicating data

TwinCAT Analytics One-Klick Dashboard

The TwinCAT 3 Analytics Logger ensures the cycle-synchronous acquisition of process and application data from the machine controller. The logger is characterized by high performance because it works directly in the real-time context of the TwinCAT controller. The data acquired is optionally transmitted to a message broker via the IoT communication protocol MQTT or stored locally in a file on the hard drive of the machine control and recorded with ring buffer functionality. The configuration necessary for this is done in Microsoft Visual Studio® within the TwinCAT project. All variables of the process image and the PLC application can easily be added to the configuration via checkbox without any programming effort.

Product status:

regular delivery

Product information

Technical dataTF3500
Required licenseTC1000
Operating systemWindows 7, Windows 10, Windows CE, TwinCAT/BSD
CPU architecturex86, x64
Ordering information
TF3500-0v20TwinCAT 3 Analytics Logger, platform level 20 (Economy)
TF3500-0v30TwinCAT 3 Analytics Logger, platform level 30 (Economy Plus)
TF3500-0v40TwinCAT 3 Analytics Logger, platform level 40 (Performance)
TF3500-0v50TwinCAT 3 Analytics Logger, platform level 50 (Performance Plus)
TF3500-0v60TwinCAT 3 Analytics Logger, platform level 60 (Mid Performance)
TF3500-0v70TwinCAT 3 Analytics Logger, platform level 70 (High Performance)
TF3500-0v80TwinCAT 3 Analytics Logger, platform level 80 (Very High Performance)
TF3500-0v81TwinCAT 3 Analytics Logger, platform level 81 (Very High Performance)
TF3500-0v82TwinCAT 3 Analytics Logger, platform level 82 (Very High Performance)
TF3500-0v83TwinCAT 3 Analytics Logger, platform level 83 (Very High Performance)
TF3500-0v84TwinCAT 3 Analytics Logger, platform level 84 (Very High Performance)
TF3500-0v90TwinCAT 3 Analytics Logger, platform level 90 (Other)
TF3500-0v91TwinCAT 3 Analytics Logger, platform level 91 (Other 5…8 Cores)
TF3500-0v92TwinCAT 3 Analytics Logger, platform level 92 (Other 9…16 Cores)
TF3500-0v93TwinCAT 3 Analytics Logger, platform level 93 (Other 17…32 Cores)
TF3500-0v94TwinCAT 3 Analytics Logger, platform level 94 (Other 33…64 Cores)

We recommend using a TwinCAT 3 license dongle for platform levels 90-94.
